Race Face Turbine Pedals

Platform pedals created for terrain where good grip alone is not enough.

Introducing the latest innovation from Race Face – Turbine platform pedals, which offer the most secure connection that clipless pedals can provide. The key to reliable grip for demanding climbs and descents is the concave shape from front to back and side to side. It creates a recess in the platform that naturally envelops your foot and, in combination with the pins, ensures uncompromising adhesion.

In addition to the concave shape, the Turbine model is also unique in its asymmetrical shape, which mimics the anatomical shape of the foot – the pedal is wider at the front and narrower at the rear. This provides excellent support while eliminating unnecessary bulk, allowing the pedal to glide smoothly through the air and avoid collisions with the surrounding terrain.

For even better pedaling ergonomics, the bushing is on the inside of the pedal, while the bearing is on the outside. This eliminates the protrusion of the bearing, which is usually located next to the crank threads. This gives you a larger effective platform, allows you to place your foot closer to the cranks, and gives you a perfect feeling of control and confidence.

Specifications

• Axle Material: Chromoly Steel
• Pedal Material: 6061 Aluminum
• Platform Concavity: 3 mm
• Platform Thickness: 20 mm (edges)
• Number of pins: 22 adjustable pins per pedal (11 per side), height 6 mm from platform
• Platform dimensions: 115 x 110 mm
• Set weight: 419 g
• The package includes 4 replacement pins and 44 pin washers (shortens the pin by 0.8 mm)
